Commercial Indoor Unit: Wall Mount

Cool every corner of the room with a series built around a high-efficiency DC motor. Its wide air supply range and uniform air flow keep the whole space comfortable, while the easy-to-remove panel makes cleaning simple. With its stylish design, it fits homes, hotels, apartments, offices and meeting rooms.
| Model | GWM-15K1D/I | GWM-18K1D/I | GWM-22K1D/I | GWM-28K1D/I | GWM-36K1D/I | GWM-45K1D/I | GWM-50K1D/I | GWM-56K1D/I | GWM-63K1D/I | GWM-71K1D/I | GWM-80K1D/I | GWM-90K1D/I | GWM-80K1D/I | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Cooling Capacity Rated (Min-Max) | kW | 1.5 | 1.8 | 2.2 | 2.8 | 3.6 | 4.5 | 5.0 | 5.6 | 6.3 | 7.1 | 8.0 | 9.0 | 9.5 |
| Power Supply | 220-240V | 50 Hz | 220-240V | 50 Hz | 220-240V | 50 Hz | 220-240V | 50 Hz | 220-240V | 50 Hz | 220-240V | 50 Hz | 220-240V | 50 Hz | 220-240V | 50 Hz | 220-240V | 50 Hz | 220-240V | 50 Hz | 220-240V | 50 Hz | 220-240V | 50 Hz | 220-240V | 50 Hz |
|
| Power Consumption | W | 20 | 20 | 20 | 20 | 25 | 35 | 35 | 50 | 50 | 65 | 80 | 80 | 100 |
| Airflow Volume (H/M/L) | m³/h | 500/440/300 | 500/440/300 | 500/440/300 | 500/440/300 | 630/460/320 | 850/580/500 | 850/580/500 | 1100/850/650 | 1100/850/650 | 1200/850/650 | 1550/1050/800 | 1550/1050/800 | 1650/1100/900 |
| Rated Current | A | 0.1 | 0.1 | 0.1 | 0.1 | 0.12 | 0.17 | 0.17 | 0.24 | 0.24 | 0.31 | 0.41 | 0.41 | 0.41 |
| Dimension (W × H × D) | mm | 845 × 209 × 289 | 845 × 209 × 289 | 845 × 209 × 289 | 845 × 209 × 289 | 845 × 209 × 289 | 970 × 224 × 300 | 970 × 224 × 300 | 1078 × 246 × 325 | 1078 × 246 × 325 | 1078 × 246 × 325 | 1350 × 258 × 326 | 1350 × 258 × 326 | 1350 × 258 × 326 |
| Net Weight | kg | 10.5 | 10.5 | 10.5 | 10.5 | 10.5 | 12.5 | 12.5 | 16 | 16 | 16 | 20 | 20 | 20 |
| Sound Pressure Level (H/M/L) | dB(A) | 35/33/30 | 35/33/30 | 35/33/30 | 35/33/30 | 38/35/31 | 43/40/37 | 43/40/37 | 43/41/37 | 43/41/37 | 43/41/37 | 49/46/40 | 49/46/40 | 52/48/40 |
| Connection Pipe Diameter (⌀) | Gas | 3/8" (9.52mm) | 3/8" (9.52mm) | 3/8" (9.52mm) | 3/8" (9.52mm) | 1/2" (12.7mm) | 1/2" (12.7mm) | 1/2" (12.7mm) | 5/8" (15.9mm) | 5/8" (15.9mm) | 5/8" (15.9mm) | 5/8" (15.9mm) | 5/8" (15.9mm) | 5/8" (15.9mm) |
| Connection Pipe Diameter (⌀) | Liquid | 1/4" (6.35mm) | 1/4" (6.35mm) | 1/4" (6.35mm) | 1/4" (6.35mm) | 1/4" (6.35mm) | 1/4" (6.35mm) | 1/4" (6.35mm) | 3/8" (9.52mm) | 3/8" (9.52mm) | 3/8" (9.52mm) | 3/8" (9.52mm) | 3/8" (9.52mm) | 3/8" (9.52mm) |
Features
Superior Air Distribution
The Wall-Mounted Indoor Unit delivers superior air distribution by utilizing an automatic up-and-down swing louver that expands coverage, allowing its wide air supply to naturally and evenly reach every corner of the room . Powered by intelligent temperature control technology, its powerful and fast cooling and heating functions rapidly bring the space to the set temperature . This creates a uniform temperature distribution and high level of comfort, ensuring that heating airflow reaches directly down to the floor to warm the entire room evenly from the ground up .
Continuous Innovation
The Wall-Mounted Indoor Unit is engineered for effortless maintenance with an easy-to-clean design that features a removable front panel and a washable long-term filter. The front panel slides smoothly in and out for simple disassembly, making it easy to wipe down so the unit maintains a fresh, clean appearance over time. Paired with a durable filter that can be quickly detached and washed, routine maintenance is hassle-free, ensuring efficient performance and clean air quality with minimal effort
Multiple Protection Functions
The Wall-Mounted Indoor Unit incorporates multiple protection functions to ensure safe, reliable, and long-term operation. These safeguards include anti-freezing protection to prevent ice buildup on the heat exchanger, built-in fan motor overload protection to guard against electrical and thermal strain, and temperature sensor error protection to maintain precise monitoring. Together, these automated features prevent system failure and extend the overall lifespan of the hardware
Easy to Install
The Wall-Mounted Indoor Unit offers an easy and flexible installation process that requires no complex architectural modifications . By mounting directly onto the wall, it eliminates the need to occupy valuable floor space or construct suspended ceilings . Combined with flexible refrigerant piping routing, it provides a fast, labor-saving setup that seamlessly adapts to a wide variety of spaces, including residential homes, apartments, offices, and hotel rooms .
Powerful And Fast Cooling
The Gree Wall-Mounted Indoor Unit utilizes intelligent temperature control technology combined with a high-efficiency DC motor and cross-flow fan blades to deliver rapid, high-capacity cooling. Designed to quickly bring indoor spaces to the desired temperature setpoint, the unit employs automatic up-and-down air louvers to distribute airflow naturally and evenly into every corner of the room while maintaining low operational noise. Once the set temperature is reached, its intelligent PID capacity control fine-tunes the climate to minimize temperature fluctuations and prevent frequent power cycling, offering immediate cooling relief alongside stable, energy-efficient comfort
Wall Mount Aircon Unit FAQ
What is a wall-mounted air conditioner?
A wall-mounted air conditioner is an air conditioning unit installed on a wall to cool or heat an indoor space. It typically consists of an indoor unit mounted high on the wall and an outdoor unit connected through refrigerant and electrical lines, making it suitable for homes and commercial spaces where floor space is limited.
Does a wall AC use a lot of electricity?
A wall-mounted air conditioner does not necessarily use a lot of electricity, as energy consumption depends on factors such as cooling capacity, operating hours, room size and energy efficiency. Inverter models can adjust compressor operation according to cooling demand, which can help reduce unnecessary energy use.
Can you leave a wall AC on all day?
Yes, a wall-mounted air conditioner can be operated for extended periods, provided the system is correctly installed and maintained. Using an appropriate temperature setting and keeping filters and other components clean can help maintain efficient operation during longer periods of use.
Does a wall AC need to be vented?
No, a split-type wall-mounted air conditioner does not need a separate window vent. The indoor unit connects to an outdoor unit through refrigerant piping, electrical wiring and a condensate drain, while heat is released through the outdoor unit.
